An Automatic Bottle External Washing Machine is an industrial or semi-industrial device designed to clean the exterior surfaces of bottles (typically glass, PET, plastic, or metal) prior to filling, labeling, or packaging in beverage, pharmaceutical, food, or cosmetic production lines. Unlike internal rinsers, these machines focus on removing dust, debris, labels, residues, and contaminants from the outside of the bottle using high-pressure jets of water, air, detergents, or sanitizing solutions. They ensure hygiene, compliance with GMP (Good Manufacturing Practices) standards, and efficiency by automating the process, reducing manual labor, and minimizing water usage through recycling systems.
Automatic Bottle External Washing Machine Video
Key Features
-
Bottle Handling: Compatible with round, flat, square, or irregularly shaped bottles. Bottles are loaded manually or via conveyor, inverted or gripped by holders for external spraying.
-
Cleaning Mechanisms:
-
High-pressure nozzles (up to 12 per station) for jetting water, air, or solutions.
-
Soaking baths for immersion (1–3 cycles) to loosen stubborn residues.
-
Label removal stations (for paper or aluminum labels) using jets or extraction tools.
-
Rinsing sequences: Pre-wash, detergent wash, recycled rinses (1–2 stages), and final fresh-water rinse.
-
-
Automation: PLC (Programmable Logic Controller) touch-screen controls for adjustable cycles, speeds, and timings. Variable Frequency Drives (VFD) for speed regulation; solenoid valves to control flow and reduce waste.
-
Materials and Durability: Constructed from stainless steel for corrosion resistance; IP55-rated electrical systems for safety.
-
Add-Ons: UV sterilization integration, self-cleaning filters, automatic temperature/speed control, and recovery basins for water recycling.
-
Power and Utilities: Typically requires 220–440V power, compressed air (6–8 bar), and water supply (2–5 bar); energy-efficient pumps for high-pressure delivery.
Operation Process
-
Loading: Bottles are placed on a rotary table, conveyor, or indexing system.
-
Pre-Wash: Initial jetting or immersion to remove loose debris.
-
Soaking/Detergent Wash: Bottles are submerged or sprayed with alkaline detergents for 5–10 minutes.
-
Label Extraction (if applicable): High-velocity jets or mechanical arms peel off labels.
-
Rinsing: Multi-stage rinses with recycled then fresh water to neutralize and remove residues.
-
Drying/Air Wash: Compressed air jets to blow-dry exteriors.
-
Unloading: Clean bottles exit to the next station (e.g., filler or dryer).
The entire cycle per bottle takes 10–30 seconds, with minimal human intervention.
Benefits
-
Efficiency: Reduces cleaning time by 80–90% compared to manual methods; handles diverse bottle sizes with quick changeovers (under 10 minutes).
-
Hygiene: Ensures spot-free, contamination-free surfaces, critical for food safety.
-
Cost Savings: Low water/chemical consumption via recycling; durable design minimizes maintenance.
-
Versatility: Suitable for new, returnable, or recyclable bottles; integrable into full packaging lines.
Salient Features of Bottle External Washing Machine
-
Compact cGMP model.
-
Suitable for vial sizes from 5ml to 100ml without any change parts (No change parts required)
-
“No Vial – No Washing” system eliminates wastage of water & air.
-
Easy cleaning & maintaining
-
Machine is equipped with PLC system.
-
Stops supply of water & air when acrylic doors opened during operation.
-
Indication & alarm in PLC.
-
Normal water required for washing & no hot water required.
-
When there is no vial on conveyor, it stops the water & air supply. Infeed & outfeed Turn Tables.
-
Imported Gear motor for main drive, unscrarnbler and scrambler.
-
Variable A.C frequency drive for main drive, unscrambler and scrambler Acrylic cabinet for machine.
* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
