An EO Sterilizer Machine, also known as an Ethylene Oxide Sterilizer, is a specialized device used for sterilizing heat-sensitive and moisture-intolerant medical equipment, pharmaceuticals, spices, and other materials that cannot withstand traditional methods like steam autoclaving or dry heat. EO gas is a powerful alkylating agent that penetrates packaging and disrupts microbial reproduction, achieving a high sterility assurance level (SAL) of 10⁻⁶. The process is low-temperature (typically 80–150°F) and environmentally controlled, making it ideal for delicate items like endoscopes, catheters, and multi-lumen devices.
EO Sterilize Machine Video
The sterilization cycle typically involves four phases:
-
Preconditioning: Conditioning the load to optimize gas penetration.
-
Sterilization: Exposure to EO gas under controlled pressure, temperature, and humidity.
-
Exhaust: Removing residual gas from the chamber.
-
Aeration: Degassing the load in a separate area to remove EO residues below safe limits.
How Does It Work?
EO sterilizers use a sealed chamber where items are placed in breathable packaging. The machine injects a microdose of EO gas (often mixed with inert gases like CO₂ or nitrogen for safety). Vacuum and pressure cycles ensure even distribution. Built-in sensors monitor parameters in real-time, with traceability features for batch reporting. Aeration can take hours to days, often in dedicated chambers. Advanced models use flexible chamber technology to minimize gas usage and reduce environmental impact.
Salient Features of ETO Sterilizer
-
Machine is suitable to Sterilize Surgical Medical Device products like I.V. Sets, Disposable Syringes, Disposable Surgical Set, catheter, Urine Bag etc.
-
ETO Sterilization reduce microbiological load and increase life span of material.
-
Modular construction of chamber.
-
Model is available from 0.5 Cubic Meters to 40 Cubic Metres.
-
Easy to operate.
-
Fully automatic operation based on PLC control.
-
Semi Automatic (Pneumatically Operated Ball Valve) Control.
-
Contact parts are SS 304 / 316.
-
Process time about 8 hours.
-
IQ/OQ/DQ documentation can be offered on demand. (OPTIONAL).
-
It is useful for prevention of micro biological contamination useful for treatment of spices, dried nuts, Foods Packed cereals etc.
Process Operation of ETO Sterilizer
Ethylene Oxide Sterilization (Sterilisation) offers various distinct advantages over the conventional steam sterilizers (sterilisers), being a DRY & COLD (operates at 50ºC ) process proves very useful in sterilization of expensive items, also it has got a unique penetration ability, so it is very useful in sterilization (Sterilisation) of expensive and delicate items such as Cardiac catheters, Stents, IOL’s Tubings, various types of scopes, sharp surgical instruments etc., its unique mode of action, also enhances the life of several surgical accessories & disposables items thus making them perfectly reusable.
Types of EO Gas Sterilizers
We are one of the leading EO Gas Sterilizer manufacturer in India. We manufacture below two types of ETO sterilizers:
Semi Automatic Operation Mode EO Sterilizer: In this type of control mode there are analog type buttons onto control panel of the machine through which machine operation procedure will be done.
Fully Automatic Operation Mode EO Sterilizer: This is PLC HMI based fully automatic control mode equipment in which there is HMI mounted onto control panel of the machine through which operation procedure done.
Technical Specification of EO Gas Sterilizer
| Model | AETOS – 2.6 | AETOS – 4.5 | AETOS – 8 |
| Working Capacity in Cu. Ft. | 2.6 | 4.5 | 8 |
| Working Volume | 70 Liters | 125 Liters | 200 Liters |
| Chamber Size | 12” (W) x 12” (H) x 32”
|
12” (W) x 12” (H) x 54” (D) OR
15” (W) x 15” (H) x 36” (D) |
20” (W) x 18” (H) x 38” (D) OR 16” (W) x 16” (H) x 54” (D) |
| Sterilant Gas | 40 grams cartridge | 100 grams cartridge | 170 grams cartridge |
| Sterilization Cycle | Warm & Cold Cycles are possible. | Warm & Cold Cycles are possible. | Warm & Cold Cycles are possible. |
| Aeration | In-built aeration facility provided. | In-built aeration facility provided. | In-built aeration facility provided. |
| Utility | Compressed Air (100 psig) | Compressed Air (100 psig) | Compressed Air (100 psig) |
| Power Supply | 1 K.W. | 2 K.W. | 2.5 K.W. |
| Power Voltage | 220 volts, Single Phase, 50 Hertz | 220 volts, Single Phase, 50 Hertz | 220 volts, Single Phase, 50 Hertz |
* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
