Capsule Filling Machine

Q: What are the different types and production capacities available?

The range includes: Manual (e.g., CFM 300): Up to 6,000 capsules per hour . Semi-Automatic (e.g., ASCF-25): Up to 25,000 capsules per hour . Automatic (e.g., ACF-40): Up to 40,000 capsules per hour . All models support capsule sizes 00, 0, 1, 2, 3, 4, and 5 with interchangeable change parts.

Q: What are the main benefits of using a Capsule Filling Machine?

High Efficiency : Significantly increases output while reducing labor and operator fatigue. Precision & Consistency : Ensures accurate dosing and uniform fill weights. Cost-Effective : Low investment and operating costs with excellent ROI. Versatility : Suitable for small to large-scale production across pharmaceutical, nutraceutical, Ayurvedic, herbal, and biotech industries. Compliance : Meets GMP standards and regulatory requirements with hygienic operation and minimal waste.

Description

Capsule Filling Machine is a device used to fill empty capsuleswith powders, pellets, granules, liquids, or other substances. These machines are essential in the pharmaceutical, nutraceutical, and supplement industries for producing capsules efficiently and accurately. They range from simple manual tools for home or small-scale use to advanced automated systems for high-volume production in commercial settings. The process generally involves separating the capsule halves, filling the bottom half, and then sealing them together. Capsule filling machines ensure precise dosing, reduce waste, and maintain hygiene standards, which is crucial for regulatory compliance in pharma applications.

If you need details on specific models and pricing, let me know!

Salient Features of Capsule Filling Machine

Compact & Space-Saving Design
Options for Stainless Steel 304 or 316 contact parts for superior corrosion resistance and product safety.
Simple mechanism that even semi-skilled operators can handle efficiently.
Supports both manual loading and automatic capsule loader/orienter for faster tray filling (one loader can support multiple filling machines).

Universal design ensures easy servicing and maintenance.
Compatible with capsule sizes 00, 0, 1, 2, 3, 4, and 5 through quick-change format parts.
Works with hard gelatin capsules, vegetarian (HPMC), and veg capsules.
Full GMP design with IQ/OQ documentation available for regulatory requirements.

Working Principle of Capsule Filling Machine

The basic workflow is similar across types:

Preparation: Empty capsules are loaded into a tray or hopper. The machine separates the top and bottom halves.

Filling: Powder or material is dispensed into the bottom halves. For manual machines, you spread and tamp the powder evenly. Automated versions use dosators, augers, or vibrators for precision.

Sealing: The top halves are aligned and joined, often with heat or mechanical pressure.

Inspection/Cleaning: Advanced machines include weight checks or vision systems; all require easy disassembly for cleaning.

Technical Specification of Capsule Filling Machine

Model	CFM 300	ASCF – 25	ACF – 40
Production Output	Up to 6000 Capsules/hour	Up to 25,000 capsules/hour	Up to 40,000 capsules
Capsule Size	00/0/1/2/3/4/5 with suitable parts	00/0/1/2/3/4/5 with suitable parts	00/0/1/2/3/4/5 with suitable parts
Types	Manual	Semi Automatic	Automatic
Power Voltage	_	415 Volts, 3 Phase, 50 Hertz	415 Volts, 3 Phase, 50 Hertz
Compressed Air	_	8 CFM at 100 PSI	4 CFM
Machine Dimensions approx. Length Width Height	405mm 300mm 455mm	1600mm 1300mm 1600mm	975mm 875mm 1955mm
Net Weight in Kgs.	43 Kgs. approx.	950 Kgs. approx.	850 kgs. approx.

* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.

Types of Capsule Filling Machine

100 Holes Capsule Filling Machine

Automatic Capsule Filling Machine

Automatic Capsule Loader

Capsule Filling Machine with Loader Orienter

Capsule Polishing Machine

Lab Scale Automatic Capsule Filler

Manual Capsule Filling Machine

Semi Automatic Capsule Filling Machine

Applications of Capsule Filling Machine

Benefits of Capsule Filling Machine

Space-Saving & Compact Design

High Efficiency & Increased Production Output

Significant Labor & Time Savings

Precision, Uniformity & Quality Compliance

Key Advantages of Capsule Filling Machine

Capsule Filling Machines offer an excellent balance between manual and fully automatic systems. Here are the key advantages that make them popular for small to medium-scale production:

High Production Output with Low Investment

Up to 6,000 capsules per hour with the bench top filler.

With automatic orienter/loader: Up to 15,000–20,000 capsules per hour.

One loader can support 2–3 filling machines, providing significantly higher throughput than manual systems without the high cost of fully automatic lines.

Compact Bench Top Design & Space Efficiency

Small footprint (approx. 405 × 300 × 455 mm).

Fits easily on a standard workbench — ideal for R&D labs, pilot plants, pharmacies, small manufacturing units, and home-based businesses.

No need for large factory space.

Significant Labor & Time Savings

Automatic loader fills a 300-hole tray in ~28–30 seconds.

Reduces manual capsule orientation and loading time by 50–70%.

Three loading trays enable continuous operation while lowering operator fatigue.

Suitable for semi-skilled workers.

Precision, Uniformity & Quality Compliance

Multiple tamping options ensure consistent fill weights for powders with different bulk densities.

Meets GMP standards with Stainless Steel 304/316 contact parts.

Supports IQ/OQ documentation for regulatory compliance.

Versatility & Ease of Use

Supports capsule sizes 00, 0, 1, 2, 3, 4, and 5 via interchangeable change parts.

Compatible with hard gelatin, HPMC, vegetarian, and veg capsules.

Optional tablet filling attachment for capsule-in-capsule production.

Quick size changeover, easy cleaning, and low maintenance.

Cost-Effective & Reliable Operation

Runs on single-phase 220V power (loader works on domestic electricity).

Low power consumption, minimal waste, and low operating costs.

Fast return on investment through higher output and reduced labor.

FAQ for Capsule Filling Machine

What is a Capsule Filling Machine?

A Capsule Filling Machine is a device used to fill empty capsules with powders, pellets, granules, liquids, or other substances. It ranges from compact manual bench-top models (like CFM 300) for small-scale use to semi-automatic and fully automatic systems for higher production. These machines are essential in the pharmaceutical, nutraceutical, Ayurvedic, herbal, and supplement industries for efficient, accurate, and hygienic capsule production.

What are the different types and production capacities available?

The range includes:

Manual (e.g., CFM 300): Up to 6,000 capsules per hour.
Semi-Automatic (e.g., ASCF-25): Up to 25,000 capsules per hour.
Automatic (e.g., ACF-40): Up to 40,000 capsules per hour.

All models support capsule sizes 00, 0, 1, 2, 3, 4, and 5 with interchangeable change parts.

Which capsule sizes and materials does it support?

It supports capsule sizes 00, 0, 1, 2, 3, 4, and 5 via quick-change format parts. The machines are compatible with hard gelatin capsules, vegetarian (HPMC), and veg capsules, making them versatile for various formulations and bulk densities.

What are the key features of the Capsule Filling Machine?

Compact & space-saving design (bench-top models fit on standard workbenches).
Stainless Steel 304 or 316 contact parts for product safety.
Manual or automatic loader/orienter options for faster operation.
Multiple tamping for uniform fill weights.
GMP-compliant design with easy cleaning, quick size changeover, and low maintenance.
IQ/OQ documentation available.
Supports continuous operation with multiple loading trays.

What are the main benefits of using a Capsule Filling Machine?

High Efficiency: Significantly increases output while reducing labor and operator fatigue.
Precision & Consistency: Ensures accurate dosing and uniform fill weights.
Cost-Effective: Low investment and operating costs with excellent ROI.
Versatility: Suitable for small to large-scale production across pharmaceutical, nutraceutical, Ayurvedic, herbal, and biotech industries.
Compliance: Meets GMP standards and regulatory requirements with hygienic operation and minimal waste.
