Bucket Conveyor

A Bucket Conveyor (also commonly known as a bucket elevator) is a mechanical system designed to transport bulk materials vertically, inclined, or horizontally using a series of buckets attached to an endless chain or belt. It is widely used in industries like agriculture, mining, food processing, and manufacturing for moving materials such as grains, powders, aggregates, fertilizers, or fragile products.

Bucket Conveyor Video

Key Components and How It Works

• Buckets: Containers (made of plastic, steel, or stainless steel) that scoop and hold the material.

• Chain or Belt: An endless loop driven by pulleys or sprockets at the top (head) and bottom (boot).

• Drive Mechanism: Typically an electric motor that powers the system.

• Loading (Boot Section): Material is fed into buckets at the bottom.

• Transportation: Buckets carry the material upward (or along the path) while remaining upright to prevent spillage.

• Discharge (Head Section): At the top, buckets tip or use centrifugal force to empty the material into a chute.

The system operates continuously, with buckets returning empty to the bottom for reloading.

Types of Bucket Conveyors

There are several main types, suited to different materials and applications:

• Centrifugal Discharge: High-speed (4-11 ft/s); uses centrifugal force to fling material out. Ideal for free-flowing, granular materials like grain.

• Continuous Discharge: Slower speed; buckets overlap for gentle handling of fragile, powdery, or sticky materials (e.g., snacks, nuts).

• Positive Discharge: Similar to centrifugal but with an extra mechanism to jolt stuck material free; best for aerated or sticky powders.

• Pendulum (Swinging) Bucket: Buckets pivot independently for complex paths (Z, C, or T shapes) and very gentle, dust-free transport; common in food industry.

Advantages

• Efficient vertical transport in limited space.

• Gentle handling minimizes product damage.

• Handles abrasive, hot, or dusty materials.

• Low maintenance and energy use compared to alternatives like pneumatic systems.

Salient Features of Conveyor

• Available in S.S./M.S. model.

• Available as per your require speed, length, height & width.

• Structure is made of S.S. 304/M.S. 32mm square pipe with matt finish/painted.

• Table top is made of S.S.304 16 gauge sheet with matt finish.

• Conveyor Belt is supplied with 3 speed pulley.

• Special Self-aligning bearing ensure smooth and trouble free rotation of the Roller.

• Conveyor belt is used as PVC coated canvas belt/endless rubberized belt.

• The Reduction Gear Box provides jerk less & noiseless performance for long time.

Technical Specification of Packaging Conveyor

* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
