Flower Basket Tablet Press Machine

Description

Flower Basket Tablet Press Machine (also known as a flower basket type continuous automatic tablet press) is a specialized piece of equipment designed for compressing granular or powdered raw materials into uniform tablets. The “flower basket” refers to its unique structural design, resembling a basket with multiple punches arranged radially, allowing for continuous and automated operation. Flower Basket Tablet Press Machine is widely used in industries like pharmaceuticals, chemicals, food processing, electronics, agriculture, and metallurgy for small-batch or laboratory-scale production. It excels at handling materials that are difficult to form, such as ceramic powders, metal powders, or large-diameter tablets, due to its high pressure and robust construction. Unlike larger rotary presses, it’s more compact and suitable for trial manufacturing, hospitals, or R&D settings.

If you need details on specific models and pricing, let me know!

Salient Features of Flower Basket Tablet Press Machine

Compact GMP Model.
Powerful Pre-Compression and Main Compression force.
Turret is driven by centrally fitted oil emerged gear box.
Available with Two Layer Tablet Compression Facility. (optional)
Maximum Speed of Turret up to 70 RPM.
100 KN Main Compression Force.
100 KN Pre-compression Force.
Available in tooling combination of D, B & BB (different models)
Pressure loading and overloading pressure release mechanism through Hydro-Pneumatic Power Pack System.

Pressure adjustment controls from outside area.
Main motor and force feeder motor driven through VFD.
Auto lubrication arrangements hence less maintenance.
Upper Punch Penetration, Anti-Vibration Mounts.
Electronic Digital Tablet Counter cum RPM indicator.
Interlock Switches to all upper guards.
Pneumatic powder loading system. (optional)
IQ/OQ documentation can be provided.
PLC system with Graphical User Interface can be offered. (optional)

Working Principle of Flower Basket Tablet Press Machine

Tablet compression machine basically works on hydraulic pressure. This pressure perform key role in any type of Tablet Machine. It transmitted unreduced through the static fluid. Any external applied pressure is transmitted through static fluid to all directions in the same proposition. which resulting make suitable to increase pressure. To form a tablet, the granulated powder material must be metered into a cavity formed by two punches and a die, and then the punches must be pressed together with great force to fuse the material together. There are two types of tablet presses called Single Station Tablet Press and Multi Station Tablet Press. Working of these machines differs in terms of production output and feature requirements.

Technical Specification of Flower Basket Tablet Press Machine

Model	16D	20D	24D	37D
Number of Stations	16	20	24	37
Type of Tooling Punch	D	D	DB	D
Output – Tablets / hour approx.	13,440 – 40,320	16,800 – 50,400	19,320 – 57,950	222000
Max. Operating Pressure	100 KN	100 KN	65 KN	100 KN
Max. Tablet Dia	25mm	25mm	16mm	25mm
Max. Depth of fill	20.5 mm	20.5 mm	17.5 mm	20mm
Upper Punch Penetration	1.5 – 8 mm	1.5 – 8 mm	1.5 – 8 mm	3 – 6mm
Main Electric Motor	3 H.P., 1440 RPM, 415 V., 3 Phase, 50 Hz.	3 H.P., 1440 RPM, 415 V., 3 Phase, 50 Hz.	3 H.P., 1440 RPM, 415 V., 3 Phase, 50 Hz.	9 H.P., 1440 RPM, 415 V., 3 Phase, 50 Hz.
Overall Dimension (cm) approx.	98 x 102 x 182 H	98 x 102 x 182 H	98 x 102 x 182 H	167 x 183 x 215
Net Weight (Kgs) approx.	1150	1150	1150	2500

* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.

Types of Tablet Press Machine

Rotary Tablet Press Machine

Lab Scale Tablet Press Machine

Single Rotary Tablet Press Machine

Double Rotary Tablet Press Machine

Heavy Duty Salt Tablet Press Machine

Heavy Duty Bolus Tablet Press Machine

High Speed Tablet Press Machine

Bi Layer Tablet Making Machine

Applications of Tablet Press Machine

Advantages of Flower Basket Tablet Press Machine

Suitable for Difficult-to-Form Materials & Large Tablets

Compact Design with High Versatility

Consistent Quality & Uniform Tablets

Efficient Operation & Low Maintenance

Key Features of Flower Basket Tablet Press Machine

Continuous Automation: Operates without interruption, pressing multiple tablets per cycle.

Versatility: Can produce round, irregular, ring-shaped, or engraved tablets (with trademarks, text, or simple graphics).

High Pressure: Supports compression of hard-to-form powders; maximum tablet diameter customizable up to 80mm in some models.

Ease of Use: Adjustable filling depth, operable manually or electrically; minimal training required.

Durability: Built with precision engineering for long-term reliability and reduced downtime.

FAQ for Flower Basket Tablet Press Machine

What is a Flower Basket Tablet Press Machine?

A Flower Basket Tablet Press Machine, also known as a Flower Basket Type Continuous Automatic Tablet Press, is a specialized rotary tablet compression machine with a unique radial “flower basket” punch arrangement. It is designed for compressing granular or powdered materials — including difficult-to-form substances like ceramics, metal powders, and chemicals — into uniform tablets. It is compact and ideal for small-batch, R&D, pilot-scale, hospital, and laboratory production across pharmaceutical, chemical, food, electronics, agriculture, and metallurgy industries.

How does a Flower Basket Tablet Press Machine work?

The machine operates on the principle of hydraulic pressure. Powder or granules are metered into a die cavity formed by upper and lower punches. The punches apply powerful pre-compression and main compression forces to fuse the material into a solid tablet. Cam tracks guide the punches through filling, compression, and ejection stages as the multi-station turret rotates continuously for efficient production.

What are the key features of the Flower Basket Tablet Press Machine?

Compact GMP model with powerful pre- and main compression forces (up to 100 KN).
Turret driven by a centrally fitted oil-immersed gearbox with speeds up to 70 RPM.
Available with optional two-layer compression, hydro-pneumatic pressure control, auto lubrication, upper punch penetration, and VFD-driven motors.
Features electronic tablet & RPM counter, anti-vibration mounts, safety interlocks, and optional PLC/HMI & pneumatic powder loading.
Tooling options in D, B, and BB configurations.

What are the production capacities and technical specifications?

Available in models 16D, 20D, 24D, and 37D with outputs ranging from 13,440 to 222,000 tablets per hour. Key specs include max compression force up to 100 KN, max tablet diameter up to 25mm (customizable higher in some variants), max depth of fill up to 20.5mm, and support for round, irregular, ring-shaped, or engraved tablets. Specifications vary by model.

What are the main advantages and applications of a Flower Basket Tablet Press Machine?

Advantages: Excellent for hard-to-form materials, high pressure capability, compact design for R&D/small batches, continuous automated operation, uniform tablet quality, versatility in shapes, easy maintenance with auto lubrication, and GMP compliance. Applications: Pharmaceutical, Chemical, Food Processing, Electronics, Agriculture, Metallurgy, and Nutraceutical industries for trial manufacturing and specialty tablet production.
