Side Grip Conveyor

A Side Grip Conveyor (also known as a side gripping conveyor, hugger belt conveyor, bottomless conveyor, or side belt conveyor) is a specialized material handling system used in industrial packaging and production lines. It consists of two parallel conveyor belts or chains positioned on opposite sides that gently grip products by their sides, holding them securely while transporting them. This design leaves the top and bottom of the product fully exposed and unsupported (hence “bottomless”).

Side Grip Conveyor Video

Key Features

• Gripping Mechanism: Products are “wedged” or “pinched” between opposing belts/chains, often adjustable in width (via hand wheels or spindles) to accommodate different product sizes without crushing them.

• Configurations: Can be horizontal (for transfers), vertical (for elevation changes, known as elevators/lowerators), inclined, or wedge-style.

• Materials: Often uses urethane gripper chains, timing belts, or table-top chains; frames can be aluminum or stainless steel for food-grade/sanitary applications.

Primary Applications

• Bottom Access: Ideal for printing/coding (e.g., expiration dates, lot numbers with inkjet printers), labeling, inspection, or cleaning the underside of containers.

• Gap Transfers: Smoothly transfers products between two conveyors, eliminating dead plates and preventing jamming.

• Elevation Changes: Lifts or lowers products (e.g., bottles, cans, cartons) over short distances or vertically in compact spaces, where standard inclines would cause slipping.

• Other Uses: Inverting products, spacing/de-pucking, uprighting fallen items, creating walk-thrus/overheads, or metering product flow.

• Industries: Common in food & beverage, pharmaceuticals, cosmetics, chemicals, and general packaging for handling bottles, jars, cans, pouches, boxes, or cases.

Advantages

• Provides secure hold during steep inclines or high speeds.

• Gentle on sensitive products with minimal contact pressure.

• Compact footprint, quick product changeovers, and integration with existing lines.

• High capacity for continuous operations.

Salient Features of Conveyor

• Available in S.S./M.S. model.

• Available as per your require speed, length, height & width.

• Structure is made of S.S. 304/M.S. 32mm square pipe with matt finish/painted.

• Table top is made of S.S.304 16 gauge sheet with matt finish.

• Conveyor Belt is supplied with 3 speed pulley.

• Special Self-aligning bearing ensure smooth and trouble free rotation of the Roller.

• Conveyor belt is used as PVC coated canvas belt/endless rubberized belt.

• The Reduction Gear Box provides jerk less & noiseless performance for long time.

Technical Specification of Side Grip Conveyor

* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
