A Compact Bottle Washer is a small, countertop appliance designed primarily for efficiently cleaning, sterilizing, and drying baby bottles, breast pump parts, pacifiers, and other small baby essentials. Unlike full-sized dishwashers, these machines are space-saving, portable, and tailored for busy parents or small households, often featuring built-in water tanks to eliminate the need for plumbing hookups. They use high-pressure jets, steam sterilization, and hot air drying to ensure hygienic results faster and more thoroughly than manual brushing or standard dishwashers.
Automatic Bottle Washer Video
Key Features of Compact Bottle Washers
-
Capacity and Design: Typically holds 4–6 bottles per cycle in a dual-layer or adjustable rack system. Compact footprint (e.g., under 12 inches wide) fits easily on kitchen counters, ideal for apartments, RVs, or dorms.
-
Cleaning Modes: Options like rapid wash (15–30 minutes), normal wash, sterilize + dry (kills 99.9% of germs via steam at 167°F/75°C), and storage mode (up to 72 hours of odor-free, dry storage with air circulation).
-
Efficiency: Uses 20–26 multidirectional spray jets for spotless cleaning, low water/energy consumption, and compatibility with most bottle brands (e.g., Dr. Brown’s, Philips Avent).
-
Additional Perks: Touch controls, pull-out drawers for easy loading, and sometimes included cleaning tablets. Some models double as mini dishwashers for utensils or toys.
Salient Features of Bottle Washing Machine
-
Geneva mechanism.
-
Four inner, one outer and one air wash.
-
Sequence of washes of washes to customer’s choice
-
Stationary nozzles eliminate contamination of water cycles.
-
Easy loading and unloading with two rows.
-
Individual solenoid valve for each washing sequence.
-
Pumps and tanks are mounted on parable stand for easy maintenance.
-
Easy operation.
-
Higher capacity centrifugal pumps to wash bigger bottles.
-
The stationary nozzles avoid chipping of bottle necks.
-
Bottle guide system especially for lightweight bottle.
-
Pumps and Tanks are mounted on portable stand for easy maintenance.
-
Separate panel control to avoid any short circuit due to spraying of water.
-
S.S. glycerin fill pressure meter.
Process Operation of Bottle Washer
The bottles are loaded on the subsequent indexing part of rotating platform and are cleared in series of operations. Specially designed bottle holders are provided to hold bottles with neck diameter. The bottles are placed in an inverted position in these cup shaped holders. Spraying showers does the external cleaning of the bottles. Solenoid valves are provided to enable the regulation of wash timings, it also spraying water when bottle are stopped means ensure saving of water and sequence of various washing media to suit specific requirement.
Technical Specification of Compact Bottle Washer Machine
|
Model No |
ARBW – 64 | ARBW – 100 |
| Production Output | Up to 60 Bottles / Minute (Depending on Bottle Size) |
Up to 100 Bottles / Minute (Depending on Bottle Size) |
|
Input Specification |
Diameter of the container: 25 mm to 100mm Outside Diameter of Neck: 20 mm to 38 mm (with the help of change parts) Height of the container: Up to 280 mm (with the help of change parts) |
Diameter of the container: 25 mm to 100mm Outside Diameter of Neck: 20 mm to 38 mm (with the help of change parts) Height of the container: Up to 280 mm (with the help of change parts) |
| Power Supply | Main Unit: 0.75 H.P., 380 Volt, 3 Phase, 4 Wire System, 50 Hz
Optional Accessories (2 Pumps – Pumping Station) 0.75 H.P., 380 Volt, 3 Phase, 4 Wires System, 50 Hz Electric Heater Tank: 2 K.W. |
Main Unit: 0.75 H.P., 380 Volt, 3 Phase, 4 Wire System, 50 Hz Optional Accessories (2 Pumps – Pumping Station) 0.75 H.P., 380 Volt, 3 Phase, 4 Wires System, 50 Hz Electric Heater Tank: 2 K.W. |
|
Overall Dimension |
1550 mm (L) x 1700 mm (W) x 1300 mm (H) approx. | 1800 mm (L) x 1700 mm (W) x 1300 mm (H) approx. |
| Air Consumption | 30 CFM @ 5 bar |
30 CFM @ 5 bar |
|
Net Weight |
650 kgs. approx. |
750 kgs. approx. |
* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
