A Confectionery Tablet Press Machine is a specialized rotary tablet compression machine designed for high-speed, high-volume production of compressed tablets in the confectionery industry. It transforms powdered or granulated ingredients (such as sugar, dextrose, sorbitol, citric acid, flavors, colors, and binders) into uniform, solid tablets like candies, mints, lozenges, chewables, or effervescent sweets.
Tablet Press Machine Video
Types of Tablet Press Machines
Our range of tableting machines consist small tablet press or mini tablet press to high speed tablet press. We specialize in designing different types of rotary tablet press machines and square tablet press machines such as:
-
8 Station Rotary Tableting Machine
-
16 Station Rotary Tableting Machine
-
27 Station Rotary Tableting Machine
-
35 Station Rotary Tableting Machine
-
45 Station Rotary Tableting Machine
-
55 Station Rotary Tableting Machine
-
61 Station Rotary Tableting Machine
Key Features and Specifications
-
Type: Single-sided or double-sided rotary press.
-
Compression Force: 40–100 kN (adjustable for dense or friable tablets).
-
Material Compatibility: Food-grade stainless steel (SS 316L contact parts); GMP-compliant for hygiene.
-
Dust Control: Integrated dust extraction system to prevent cross-contamination.
-
Automation: PLC-controlled with HMI touchscreen; auto-lubrication, weight adjustment, and rejection of defective tablets.
-
Safety: Overload protection, emergency stop, and enclosed design to meet FDA/USDA standards.
Working Principle
-
Feeding: Granulated mix is fed via gravity or force feeders into die cavities on a rotating turret.
-
Compression: Upper and lower punches compress the powder under high pressure.
-
Ejection: Formed tablets are ejected and collected via a chute.
-
Optional Add-ons: Cooling tunnels, dedusters, or metal detectors for post-compression processing.
Applications
-
Hard candies (e.g., breath mints).
-
Medicated confectionery (vitamin gummies, throat lozenges).
-
Functional sweets (energy tablets, probiotic chews).
Advantages
-
Ensures uniformity in size, weight, and dissolution.
-
High efficiency with minimal waste (<1%).
-
Scalable for small-batch R&D or large-scale production.
Technical Specification of Rotary Tablet Press Machine
|
Model |
16D | 20D | 24D | 37D |
| Number of Stations | 16 | 20 | 24 |
37 |
|
Type of Tooling Punch |
D | D | DB | D |
| Output – Tablets / hour approx. | 13,440 – 40,320 | 16,800 – 50,400 | 19,320 – 57,950 |
222000 |
| Max. Operating Pressure | 100 KN | 100 KN | 65 KN | 100 KN |
| Max. Tablet Dia | 25mm | 25mm | 16mm |
25mm |
|
Max. Depth of fill |
20.5 mm | 20.5 mm | 17.5 mm | 20mm |
| Upper Punch Penetration | 1.5 – 8 mm | 1.5 – 8 mm | 1.5 – 8 mm |
3 – 6mm |
|
Main Electric Motor |
3 H.P., 1440 RPM, 415 V., 3 Phase, 50 Hz. | 3 H.P., 1440 RPM, 415 V., 3 Phase, 50 Hz. | 3 H.P., 1440 RPM, 415 V., 3 Phase, 50 Hz. | 9 H.P., 1440 RPM, 415 V., 3 Phase, 50 Hz. |
| Overall Dimension (cm) approx. | 98 x 102 x 182 H | 98 x 102 x 182 H | 98 x 102 x 182 H |
167 x 183 x 215 |
|
Net Weight (Kgs) approx. |
1150 | 1150 | 1150 |
2500 |
* Power voltage can be adjusted as per customer’s domestic power voltage requirements.
* Rights of technical improvements & modification reserved.
* Illustrations & dimensions are shown for information purpose only.
